Agricultural Machinery Bearing GW209PPB2 Steel Bearing CR15 Certified ISO9001
GW209PPB2 Agricultural Machinery Bearing
45.000*85.000*30.175mm Bearing Features:
Inner Ring Diameter (bore):1.7717 Inch
Outer Ring Diameter: 3.3465 Inch
Width:1.1880 Inch
Dynamic load:7350
The static load:4150
Weight:1.44KG
GW209PPB2 Agricultural Machinery Bearing Description:
| Model Number | GW209PPB2 |
| Inside Diameter: | 1 49/64 |
| Outside Diameter: | 3 11/32 |
| Thickness: | 1 3/16 |
| Seal Type: | Double Shielded, 2RS |
| Material: | Chrome steel, Gcr15 |
| Precision Rating: | P0-P5 |
| Brand: | TOPE or other brands |
| Payment term: | T/T,L/C,Western Union, PayPal |
| Delivery time: | 1-5 days for small amout, 15-40 days for big amount |
GW209PPB2 Agricultural Machinery Bearing
more models:
| Bearing type | Style | d | D | Be | Bi | Dynamic load | The static load | Weight Lbs. |
| GW209PPB2 | 3 | 1.7717 | 3.3465 | 1.1880 | 1.1880 | 7350 | 4150 | 1.44 |
| 45.000 | 85.000 | 30.175 | 30.175 | | | |
| GW209PPB4 | 3 | 1.5350 | 3.3465 | 1.1880 | 1.1880 | 7350 | 4150 | 1.65 |
| 39.000 | 85.000 | 30.175 | 30.175 | | | |
| GW209PPB11 | 1 | 1.7810 | 85.000 | 0.8660 | 1.4380 | 7350 | 4150 | 1.37 |
| 45.237 | 85.000 | 22.000 | 36.525 | | | |
| GW210PPB2 | 3 | 1.9380 | 3.5433 | 1.1880 | 1.1880 | 7880 | 4650 | 1.50 |
| 49.225 | 90.000 | 30.175 | 30.175 | | | |
| GW210PPB5 | 3 | 1.7850 | 3.5433 | 1.1880 | 1.1880 | 7880 | 4650 | 1.8 |
| 45.339 | 90.000 | 30.175 | 30.175 | | | |
| GW210PP9 | 5 | 1.9450 | 3.5433 | 0.9060 | 1.4380 | 7880 | 4650 | 1.75 |
| 49.403 | 90.000 | 23.000 | 36.525 | | | |
| GW211PP2 | 4 | 2.1880 | 3.9370 | 1.3120 | 1.3120 | 9740 | 5850 | 3.00 |
| 55.575 | 100.000 | 33.325 | 33.325 | | | |
| GW211PPB2 | 3 | 2.1880 | 3.9370 | 1.3120 | 1.3120 | 9740 | 5850 | 2.62 |
| 55.575 | 100.000 | 33.325 | 33.325 | | | |
| GW211PPB8 | 1 | 2.1880 | 3.9370 | 0.9840 | 1.3120 | 9740 | 5850 | 1.85 |
| 55.575 | 100.000 | 25.000 | 33.325 | | | |
| GW211PPB9 | 1 | 2.1950 | 3.9370 | 0.9840 | 1.5620 | 9740 | 5850 | 2.02 |
| 55.753 | 100.000 | 25.000 | 39.675 | | | |
| GW211PPB10 | 3 | 1.9380 | 3.9370 | 1.3120 | 1.3120 | 9740 | 5850 | 2.26 |
| 49.225 | 100.000 | 33.325 | 33.325 | | | |
| GW211PPB13 | 1 | 1.7850 | 3.9370 | 0.9840 | 1.3120 | 9740 | 5850 | 2.02 |
| 45.339 | 100.000 | 25.000 | 33.325 | | | |
| GW211PPB14 | 1 | 2.0150 | 3.9370 | 0.9840 | 1.3120 | 9740 | 5850 | 2.00 |
| 51.181 | 100.000 | 25.000 | 33.325 | | | |
| GW211PP25 | 5 | 1.7800 | 3.9370 | 1.3120 | 1.7500 | 9740 | 5850 | 2.44 |
| 45.212 | 100.000 | 33.325 | 44.450 | | | |
| GW214PP2 | 4 | 2.7559 | 4.9213 | 1.5620 | 1.5620 | 14000 | 8800 | 4.19 |
| 70.000 | 125.000 | 39.675 | 39.675 | | | |
| GW214PPB2 | 3 | 2.7559 | 4.9213 | 1.5620 | 1.5620 | 14000 | 8800 | 3.96 |
| 70.000 | 125.000 | 39.675 | 39.675 | | | |
| GW214PPB3 | 3 | 1.9380 | 4.9213 | 1.5620 | 1.5620 | 14000 | 8800 | 4.24 |
| 49.225 | 125.000 | 39.675 | 39.675 | | | |
| GW214PPB5 | 2 | 2.7559 | 4.9213 | 1.5620 | 2.4380 | 14000 | 8800 | 4.75 |
| 70.000 | 125.000 | 39.675 | 61.925 | | | |
| GW214PPB6 | 1 | 2.6881 | 4.9213 | 1.1024 | 2.6875 | 14000 | 8800 | 5.14 |
| 68.278 | 125.000 | 28.000 | 68.263 | | | |
GW209PPB2 Agricultural Machinery Bearing Competition Advantages:
1 .Coaxiality of the sealing contact surface means that the sealing function and service life have been significantly improved
2. The outer cover extends toward the width of the sealing ring to ensure the protection of the sealing lip against mechanical damage.
3. Galvanized inner cover and outer cover
GW209PPB2 Agricultural Machinery Bearing Applications:
1. Plough disc connection bearing
2. Tillers, tractors, lawn harvesters,
3. Balers and high-power harvesting machines
4. Such as green feed harvesters and combine harvesters
Shipping Methods:
1. For small amount (GW<100KGS), we can send you by express, such as DHL, Fedex, TNT etc
2. For GW between 100KGS to 500KGS, we can send you by sea shipping or air shipping
3. For large amount (GW > 500KGS), we can send you by
Factory Photos:
How to place an order:
1. Send us your bearing inquiry, including your bearing models, your quantity. If you have brand requirement, please tell us which brand do you need as well.
2. We will quote bearing price for you. Moreover, According to the quantity of goods, we will give you different options of transportation.
3. If you agree with our price, we will make proforma invoice for payment
4. After payment is done, we will start to prepare bearings and arrange shipment
FAQ:
Q: Are you a trading company or a factory?
A: We have both. We are trading company and we have own factory.
Q: What is the delivery time if we place an order?
A: For small orders, our delivery time is 3 days. If the amount is large, usually our delivery time is 7-20 days.
Q: What is your payment term?
A: We accept T/T, W/U, PayPal and L/C.
Q: Do you have a warranty on bearings?
Answer: In normal use, our bearing guarantee period is 1 year.
